Description
Front Panel Width Adjustment
- 800mm front: adjusts from 782mm to 850mm
- 850mm front: adjusts from 832mm to 900mm
- 900mm front: adjusts from 872mm to 990mm
- 1050mm front: adjusts from 972mm to 1090mm
- 1200mm front: adjusts from 1072mm to 1230mm
- 1350mm front: adjusts from 1208mm to 1370mm
- 1500mm front: adjusts from 1388mm to 1550mm
Return Panel Width Adjustment
- 850mm return: adjusts from 830mm to 850mm
- 890mm return: adjusts from 870mm to 890mm
- 910mm return: adjusts from 890mm to 910mm
- 1010mm return: adjusts from 990mm to 1010mm
Key Features:
-
Fully Reversible Door
Left or right opening – no hassle! Just flip and rotate the pre-assembled door and fixed panel to suit your layout. -
Magnetic Closure & Water Seals
Enjoy quiet, secure door closure with the full-length magnetic seal—plus bottom seals to keep water where it belongs. -
Slimline U Channels
Accommodates out-of-square walls for a professional finish, even in imperfect spaces. -
Easy Return Panel Installation
The included 90° adapter slots effortlessly into the inline panel—just slide the return panel in to complete the setup. -
Telescopic Width Adjustment
Innovative extrusion allows the door panel to extend in and out for a precise, adjustable fit. Ideal for a wide range of shower recess sizes. -
Versatile Installation Options
Suitable for both tiled floors and standard shower bases.
Optional Sill-Less Doorway
This Trilogy front/door screen can be converted to a sill-less doorway configuration using the matching Trilogy Sill-Less Shower Kit – Matt Black, sold separately. The kit is width adjustable to suit all stocked Trilogy door sizes and includes two end caps, one door seal and one floor threshold.
Front-and-return installations: The sill-less kit modifies the front/door section only. The return panel remains framed as supplied.
Project-specific waterproofing, accessibility and building compliance depend on the complete bathroom design and installation. Confirm requirements with your installer or building certifier before ordering.
