Drainlab – Linear Drain Tile Insert 3600L x 35mmH Suits Up To 19mm Thick Tile – Satin

• Brushed anodised aluminium finish

• Complete kit includes: (1) tile insert profile (2) drain base (3) side inserts x 2 (4) end plates x 2 (5) CSK SS304 fixing screws x 4

• 10mm thick tile (or thinner) can be used with the 20mm high or 35mm high complete kits

• 19mm thick tile (or thinner) can be used with the 35mm high complete kit

• End caps are screwed on for enhanced water seal

• Adjust length by trimming to size using drop saw with appropriate cutting blade

• Self-cut drain hole at desired location. Refer page 17 for hole saw bits

NOTE: Each length is supplied longer than the specified length to allow for trimming to exact size onsite (for 1200mm length, supplied approx. 60mm longer; for 3600mm length, supplied approx. 200mm longer)
